Hydraulic briquette machine

Hydraulic briquette machine

Theoretical yield:2-28(t/h) Diameter of Roller: 500-1000mm Applied materials:Pulverized coal, coking coal, iron powder, aluminum powder, scrap iron, graphite, clay, kaolin, desulfurization gypsum, cryolite, chemical fertilizer, limestone, carbon powder, activated carbon, coke powder, tailings, slag, sludge, etc

Similar Products

The hydraulic briquette machine or hydraulic briquetting machine can compress all kinds of ore powder, metal powder, coal powder, charcoal powder and other materials. It can produce the finished products with the features of high density, high strength and high hardness because of the pressing action of two rollers.

Hydraulic Briquette Machine

Fote hydraulic briquette machine can compress all kinds of ore powder, metal powder, coal powder, charcoal powder and other materials. Hydraulic briquetting machine can produce the finished products with the features of high density, high strength and high hardness because of the pressing action of two rollers.

Hydraulic Briquette Machine

Fote hydraulic briquette machine or hydraulic briquetting machine can be used for pressing various materials such as graphite powder, fly ash, scale cinder, vanadium titanium ores, steelmaking refining agent, silicomanganese alloy, iron fine mean, carbon dust, quicklime powder, magnesia powder, copper concentrate, chromium ore powder, lead and zinc waste, bauxite, ceramic and the powdery materials in non-ferrous industry, refractory industry, etc to press materials to pellets with high density through high pressure.

Fote hydraulic briquette machine

Leave us a message for more product details and price list?

Technical Parameters

Model Roll diamter
(mm)
Roll width
(mm)
Total pressure
(t)
Main motor power
(kw)
Output
(t)
Weight
(t)
GY520-150 520 196 150 55 2.2-3.5 13
GY650-220 650 200 220 110 4-6.5 19.2
GY750-300 750 280 300 185 6-8.5 34
GY1000-350 1000 440 350 250 10-15 50.8
GY1000-450 1000 504 450 280 14-17 58.5
GY1000-500 1000 504 500 315 15-20 58.5
GYS1000-500 1000 600 500 280 17-21 56.5
GY1000-540 1000 900 540 185Kw×2 30-35 60
GY1200-800 1200 900 800 280Kw×2 40 110
GY1400-1000 1400 1000 1000 400Kw×2 50 156

Send Message

Please enter your demand such as Raw material type, Capacity, Feeding material size, Final product size, etc. To become our quality clients will have access to a discount of countract!
